DetailsAdvanced Functions Enable/Disable Wireless Radio, WDS Bridge,
WMM, Wireless Statistics
Bandwidth Signal Rate
2.4GHz: Up to 300Mbps 5GHz: Up to 867Mbps
Number of Antennas 4
Protocols IPv4 and IPv6
Standards Wi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
Transmit Power CE: <20dBm(2.4GHz), <23dBm(5GHz) FCC: <30dBm
Wireless Speed AC1200
5 GHz: 867 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n)
Antenna Type 4 External Antennas
Wireless Security Network Security
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
IoT Security
Guest Network
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
WiFi Encryption
WPA
WPA2
WAP3
WPA/WPA2-Enterprise (802.1x)
Provides WPA/WPA2 and WPA-PSK/WPA2-PSK authentication and TKIP/AES encryption
security Provides 64/128-bit WEP encryption security.
Frequency 2.4GHz and 5GHz
Ethernet 1× 10/100 Mbps WAN Port
4× 10/100 Mbps LAN Ports
Battery And Power
Power Supply 12VDC/1.0A
Power 9 V ⎓ 0.85 A
Ports
Interface 4x10/100 Mbps LAN Ports
1x10/100 Mbps WAN Port
Software
Software Features Quality of Service
WMM, Bandwidth Control
WAN Type
Dynamic IP, Static IP, PPPoE, L2TP, PPTP
Management
Access Control, Local Management, Remote Management
DHCP
Server, Client, DHCP Client List, Address Reservation
Port Forwarding
Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS - DynDns, NO-IP
Access Control
Parental Control, Local Management Control,
Host list, Access Schedule, Rule Management
Special Features
Certifications FCC, CE, RoHS
Software Protocols - IPv4 / IPv6
EasyMesh
Mesh networking creates smooth, fast, stable roaming. Archer
C50 can build an EasyMesh network with devices
that use EasyMesh technology. It also works with other TP-Link products to create a OneMesh network. Eliminate Wi-Fi
dead zones, expand your network, and fill your entire
home with high-speed Wi-Fi.
Parental Controls
URL Filtering
Time Controls
WAN Types - Dynamic IP / Static IP / PPPoE / PPTP
L2TP
Quality of Service - QoS by Device
Cloud Service - OTA Firmware Upgrade
TP-Link ID / DDNS
NAT Forwarding - Port Forwarding / Port Triggering / DMZ
UPnP
IPTV - IGMP Proxy / IGMP Snooping / Bridge / Tag VLAN
DHCP
Address Reservation
DHCP Client List / Server
DDNS - TP-Link / NO-IP / DynDNS
